Air Quality Analyzers
Mod. 529/NR/S Specific HC analyzer
Specific hydrocarbon and TVOC analyser
Technical specifications
- Measuring range
- 0–10,000 ppmV TVOC; individual ranges per compound
- Measuring scales
- 6 scales from 0–5 ppmV VOC
- Measuring cycle
- 180–300 s (shorter on request)
- Linearity
- > 1 % of f.s.d.
- Sample flow rate
- 500 ml/min
- Working temperature
- 0–40 °C
- Analog outputs
- 3× 0–10 V / 4–20 mA (specific, TVOC, difference)
- Serial output
- RS-232
- Dimensions
- 480 × 190 × 560 mm
- Weight
- 15 kg
- Power supply
- 230/110 Vac, 50/60 Hz, max 300 VA
Key features
- GC separation for specific compounds plus total VOC channel
- Separate analogue outputs for compound, TVOC and difference
- Programmable ranges per compound
- Measuring cycle 180–300 s (configurable)
- Colour touch display with live analysis view
- 19″ rack automatic operation
Typical applications
- Monitoring of specific VOC compounds in air
- Research programmes requiring compound-specific data
- Comparison of speciated vs total VOC concentrations
- Specialised immission studies
